SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling

SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling
SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling

Image Grand :  SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling

Détails sur le produit:
Lieu d'origine: Hunan, Chine
Nom de marque: SOLLROC
Conditions de paiement et expédition:
Quantité de commande min: 1
Prix: $1,500
Contact

SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling

description de
Poids: 63,0 kg Matériel: Acier carbureux
Taille de marteau: 4,5 pouces Diamètre externe: 116mm
Longueur: 1191 mm Gamme de trous: 120 mm-135 mm
A mordu la jambe: SRE 543 Thread de connexion: 3,5 '' / 4 '' Remet 4'''Metzke
Pression de travail: 10,5-3,5 Mpa Taux d'impact: 35HZ
Vitesse de rotation: 25 à 40 r/min Consommation d'air 1,7 MPA: 12M3/min
Consommation d'air 2,4MPA: 18m3/min Consommation d'air 3.0 MPA: 26m3 / min
Type de machine: Outil de forage
Mettre en évidence:

4.5inch RC Hammer

,

116mm External Diameter Reverse Circulation Hammer

,

120-135mm Hole Range DTH Hammer

SRC543 RC Reverse Circulation Hammer for Mining
Technical Specifications
Parameter Value
Length (Without bit) 1191mm
Weight (Without bit) 63.0kg
External diameter 116mm
Bit Shank SRE 543
Hole range 120-135
Connection thread 3.5''/4'' Remet
4''Metzke
Working Pressure 1.5-3.5Mpa
Impact rate at 2.4Mpa 35Hz
Recommended rotation speed 25-40r/min
Air consumption 1.7Mpa: 12m³/min
2.4Mpa: 18m³/min
3.0Mpa: 26m³/min
Product Description
We manufacture and supply premium quality DTH Hammers designed for high-pressure drilling rigs. Our hammers are constructed with superior raw materials and precision engineering to ensure durability and performance. Available in various technical specifications, these hammers offer excellent value for industrial drilling applications.
Key Features
  1. Reduces overall drilling costs by up to 40% compared to conventional methods
  2. Faster completion of drilling process with quicker results
  3. Safe operation with reduced manpower requirements
  4. Lower water consumption than alternative mining methods
  5. Simple and easy to operate
  6. Efficient sample collection with precise depth tracking for accurate mineral deposit location
Delivery Information
Standard delivery time: 15-25 days
Express delivery (when in stock): 3-5 days
Product Images
SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling 0
SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling 1
SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling 2
Related Products
DTH Hammers DTH Bits RC Hammers RC Bits Button Bits ODEX System
SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling 3
SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling 4
SRC543 RC Reverse Circulation Hammer with 4.5inch Hammer Size 116mm External Diameter and 120-135mm Hole Range for Mining and Water Well Drilling 5
